10-Points Touch Bluttoth 4G Hotel Terminal Self Service Kiosk smart hotel
Contact Person : Morgan Zhao
Phone Number : +86 18122345571
WhatsApp : +8618122345571
| Minimum Order Quantity : | 1 | Price : | negotiable |
|---|---|---|---|
| Packaging Details : | carton | Delivery Time : | 5-8 workdays |
| Payment Terms : | T/T |
| Place of Origin: | China | Brand Name: | KER |
|---|
|
Detail Information |
|||
| Dimension (W*D*H): | 169*193*104.30mm (without Cover) | Field Of View: | 127mm*88mm |
|---|---|---|---|
| Interface: | USB 2.0 | Resolution: | 500 DPI |
| Illumination: | Visible, IR (850nm) And UV (365nm) | Image Format: | JPG, BMP, PNG |
| Highlight: | 500DPI OCR Passport Scanner,850nm OCR Passport Scanner,IR OCR Passport Scanner |
||
Product Description
Features
Read ICAO compliant & Non-ICAO documents
Obtain digital data from contactless chips(RFID)
Capture images in white, IR & UV Illuminations
Suitable for self-service kiosk integration
Combine with high accuracy OCR SDK
Provide customization OCR service
Specification
| Supported Documents | |
|
Machine Readable Zone |
ICAO 9303 standard compliant documents: |
| ID-1 (Identity Card) | |
| ID-2 (Passport, Visa) | |
| ID-3 (Passport) | |
| Visual Inspection Zone | Customization based on clients’ requirements |
| RFID | Read and write contactless ICs according to ISO/IEC 14443-S (Type A/B) |
| Read smart card according to ISO/IEC 7816 | |
| Support e-passport Basic Access Control (BAC) & Extended Access Control (EAC) | |
| Support active/passive authentication | |
| Barcode | 1D: Code 128, Code 39, Interleaved 2 of 5 |
| 2D: PDF 417, QR Code, Data Matrix , Aztec Code | |
| Image | |
| Resolution | 500 DPI |
| Illumination | Visible, IR (850nm) and UV (365nm) |
| Color Depth | 24 bits/pixels |
| Sensor | CMOS, 500 Megapixels (2592*1944) |
| Image Format | JPG, BMP, PNG |
| Field of View | 127mm*88mm |
| Software | |
| Supported Operation System | Windows 7,8,10,Vista,XP (32/64 bit WHQL certified)
Windows Server 2003 & 2008 (32/64 bit) Linux Ubuntu, CentOS, RedHat Android |
| Development kit | Complete OCR SDK including DLLs,
OCXs, WebSocket, Samples and Demo program |
| Programming Languages | C#, C/C++, Java, Delphi, Visual Basic 6.0, VB.NET |
| Hardware | |
| Dimension (W*D*H) | 169*193*104.30mm (without Cover)
169*193*143.80mm (with Cover) |
| Interface | USB 2.0 |
| Status LEDs | Power, Ready, Error and Warning |
| Buzzer | Build-in buzzer |
| Power | Input: AC 100~240V, 50-60Hz, 0.8A
Output: DC 12V, 2A |
| Operating humidity | 20%-95%(non-condensing) |
| Operating temperature | -10℃ to 50℃ operating
-20℃ to 50℃ storage |
| Warranty | 1 year warranty, extensible |
